Macro Ports

DX Macro Port 15

Product No. 30139

[Compatible Lens]
Canon EF-S 35mm Macro IS STM

* Although the port has an M67 screw mount, no close-up lens can be used due to the lens's very short close focusing distance.

Port mounted on housing and the lens's close focusing distance.

Sample Images

Specifications
[Dimensions (DIAxD)] 132x48mm / 5.2x1.9inches
[Weight] Approx. 308g / 10.9 oz
[Depth rating] 100m / 330ft
[Construction] Corrosion-resistant aluminum alloy (anodized, anti-reflection coating on the inner surface) + Tempered glass
[Distance] Between the port mount and inner glass surface : 14.5mm

Manual Download

manual_en_30139_dx_macroport_15.pdf

DX Macro Port 60
Scheduled to launch in December 2022

Product No. 30140

[Compatible Lens]
Canon RF85mm F2 MACRO IS STM
Sony FE 50mm F2.8 Macro
Nikon AF-S Micro NIKKOR 60mm F2.8G ED

* M67 diameter mount screw (threaded) is provided at the tip of the port.

Specifications
[Dimensions (DIAxD)] 128x93.5mm / 5x3.7inches
[Weight] Approx. 435g / 15.3 oz
[Depth rating] 100m / 330ft
[Construction] Corrosion-resistant aluminum alloy (anodized, anti-reflection coating on the inner surface) + Tempered glass
[Distance] Between the port mount and inner glass surface : 60mm

Manual Download

manual_en_30140_dx_macroport60.pdf

DX Macro Port 87

Product No. 30119

[Compatible Lens]
Canon EF100mm F2.8L Macro IS USM
Canon RF100mm F2.8L Macro IS USM
Nikon AF-S VR Micro Nikkor ED105mm F2.8G (IF)
Nikon AF-S DX Micro Nikkor 85mm F3.5G ED VR

* This port accommodates listed lenses without additional port-base or extension ring. Port has M67 screw mount.

Specifications
[Dimensions (DIAxD)] 128x120.5mm / 5.0x4.7inches
[Weight] Approx. 505g / 17.8 oz
[Depth rating] 100m / 330ft
[Construction] Corrosion-resistant aluminum alloy (anodized, anti-reflection coating on the inner surface) + Tempered glass
[Distance] Between the port mount and inner glass surface : 87mm / 3.4 inches

Manual Download

manual_en_30119_ex_macroport_87.pdf
