◆ SEA&SEA — STROBE
Ref. 03124
Depth75 m
ModeTTL / Manual
SeriesYellow Sub
◆ Strobe / YS
TTL / Manual

YS-01 SOLIS A Long-Running Best-Seller Gets a Makeover.

Color
Product No.03124(Black)

Equipped with features found in higher-end models, it has evolved into a higher-performance device.

01 Depth ratingFans & Technical 75 m
02 Flash OutputWatt-second GN20
03 TemperatureColor 5600K
04 Beam angleWide 100°×100°

Features

01. Equipped with the same DS-TTL ll circuitry as superior Sea&sea’s high-end models

The DS-TTL ll circuitry helps emit the correct amount of light automatically based upon light intensity from the camera’s onboard flash. The strobe allows you to adjust light intensity stronger or weaker from programed standard exposure. With this function, even an inexperienced underwater photographer can instinctively control the desired amount of light.Example: If you are using two YS-01 Solis strobes, one on the right and the other on the left, and there is white soft coral to the right of your photographic subject, you can just delicately lessen light intensity from the strobe on the right alone by just turning the light level control to minus. With the improved circuitry, you can realize desired lighting for all your underwater images in a breeze.


02. Increased light intensity from the target light

Compared with the predecessor model, lighting intensity of the YS-01 Solis’ target light is 40% stronger increasing the visibility of the light axis has improved helps you understand position of the strobe position more accurately. (300lumen)


03. Superior light distribution and wide beam angle

 Because of exclusively designed prism lens, the YS-01 Solis realizes a wide beam angle of 100°x 100°with ideal flat light distribution even when the accessory diffuser is not attached. With the diffuser, light will soften and beam angle will increase to 110°x 110°




Specifications
Guide Number
20 (ISO 100/m, land)

Beam Angle
100°x100° / 110°x110° (with diffuser)

Batteries
4xAA Alkaline (6V) / 4xAA Ni-MH (4.8V)

Number of Flashes
Alkaline: 230 / Ni-MH: 300

Recycle time (full)
Alkaline: 2.5 sec. / Ni-MH: 1.9 sec.

Color Temperature
5600K / 5250K (w/diffuser)

Depth Rating
75m / 250ft

Dimensions (WxHxD)
75 x 111 x 129 mm / 4.0 x 4.4 x 5.1 inches

Weight
441g / 14.7oz (w/o batteries, fixing bolt attached)

Underwater Weight
Approx. +60g / 0.35oz (incl. batteries)

Features & Functions
  • • Exposure control: DS-TTL II (+4 steps / -5 steps)
  • • Light level control dial (GN): 1 / 1.4 / 2 / 2.8 / 4 / 5.6 / 8 / 11 / 16 / 20 (10 steps)
  • • Pre-flash control equipped with pre-flash cancel mode
  • • Auto power OFF function
  • • Sync cord: Fiber-Optic Cable
  • • Over-pressure relief valve
  • • LED target light: 300 lumen

Set Items
Fixing Bolt Diffuser

Caution
• CAUTION:
  • Use of genuine SEA&SEA Fiber-Optic Cables is recommended. Strobes may not function properly (especially TTL auto exposure) with third-party cables.
  • Do not use non-recommended batteries (such as lithium primary batteries). Doing so may cause battery leakage, overheating, or rupture resulting in personal injury.
MANUAL DOWNLOAD

You can find detailed instructions on how to operate and maintain the product.

MANUAL Compatibility List Strobe vs. Light


Product Comparison

YS-D130R
YS-D3 DUO
YS-01 SOLIS
Flash Output
130Ws
90Ws
49Ws
Flash Modes
DS-TTL
RC
HSS
Manual
DS-TTL
RC
Manual
DS-TTL
Manual
Light-emitting Tube
Circular
Straight x2
Straight
Power Supply
Dedicated Li-ion rechargeable battery
AA batteries x4
AA batteries x4
AA batteries x4
Recycle Time (Full)
Li-ion : 0.8 sec.
Ni-MH : 2.5 sec.
Alkaline : 4.0 sec.
Ni-MH : 1.7 sec.
Alkaline : 3.5 sec.
Ni-MH : 1.9 sec.
Alkaline : 2.5 sec.
Beam Angle
80x82 Degrees
102x102 Degrees(w/Diffuser)
80x105 Degrees
100x110 Degrees(w/Diffuser)
100x100 Degrees
Color Temperature
5600K
5600K(w/Diffuser)
5800K
5500K(w/Diffuser)
5600K
5250K(w/Diffuser)
Target Light
max.300 Lumens
Adjustable from 5% to 100%
max.300 Lumens
150/300 Two-Stage Adjustment
300 Lumens
Weight on Land
(w/o battery)
715g
610g
441g
Weight in Water
(w/ battery)
Li-ion : 30g
AA : 50g
-20g
60g
Dimensions
(W×H×D)
98×110×157mm
92×111×147mm
75×111×129mm
Depth Rating
100m
100m
75m


Related Items

Spare O-ring
Product No. 10580
Fiber-Optic Cable II S/2 Connectors
Product No. 50135
